Brembo MotoGP 19x

The Brembo Racing MotoGP 19×18 XA7G715 CNC radial brake master cylinder represents the pinnacle of braking technology, designed to deliver uncompromised performance on the track. Used in MotoGP and SBK, this master cylinder is CNC-machined from solid billet with titanium components, ensuring lightweight construction, exceptional strength, and absolute precision.

The hard anodized finish guarantees maximum durability and wear resistance, while the folding lever enhances safety by reducing the risk of breakage in case of a crash. Additionally, this master cylinder is pre-configured for an LVDT sensor, enabling data acquisition on brake lever travel for advanced performance analysis.

Technical specifications:

• Product code: XA7G715
• Piston diameter: Ø 19 mm
• Mounting distance: 18 mm
• CNC-machined construction, featuring titanium components for weight reduction and superior strength.
• Hard anodized finish, ensuring durability and wear resistance.
• Folding lever, designed to minimize breakage risk in the event of a crash.
• Pre-configured for LVDT sensor, allowing brake lever travel data acquisition.
• Optimized weight, improving motorcycle handling and overall performance.
• Bleed screw torque: 12÷16 Nm.
• Perfect for high-level racing applications, providing unparalleled precision and modulation
