FEATURES

• Replacement OEM stock Triumph instrument (Speedo & Tachometer) for classic models liquid cool year 2016+

• Easy to install (Plug n play).

• Use single ( i ) button for all control.

• Support ON-OFF ABS & Traction control.  *Depended on model.

• Support Mode : Road , Rain , Sport.  *Depended on model.

• Build-in flasher relay with speed flash adjust *Support 5w-40w

• Speed / RPM digital pulse output. Oil pressure & neutral (-Gnd), Turn & high beam (+12v.)

• Support third party or universal instrument (such as : Motogadget, KOSO, Daytona)   *Tested only.

SPECIFICATIONS

• Dimension 25x45x53 mm. (W x L x H).

• Weight ~ 65 grams.

• Waterproof. (IP28)

• Operating temperatures range ( -20 to +65 C° ambient )

• Supply voltage operate 8 – 16 Volt.

INDICATOR LIGHT

• Oil / Engine  indicator

       Oil pressure / Engine light

• Turn indicator

       Turn / Low fuel

• Neutral  indicator

       Neutral gear / Side-stand

• H-Beam  indicator

       High beam / Coolant temp over 110 C°

SPECIAL FUNCTION

• Riding MODE, Traction & ABS ON-OFF memory (No reset / Last setting ).

• Fuel level. ( Display via instrument speed & rpm )

• 6 Output LED

      Customization to ABS indicator, Traction control indicator, Gear position indicator, RPM +Shift light,

      Speed limit warning, Cruise controls signal indicator, Mode ridding indicator.​

• Build-in Diagnostic Clear engine code function.

• Self test speed & RPM.

• Adjustable wheel circular & Pulse/Rev. Include engine RPM pulse/Rev.
